SHORT LOOP SAMPLER – (OIL IN WATER / WATER IN OIL) ANALYZER

The SHORT LOOP SAMPLER™ combines a sampling point with the INFLOW™ Particle Analyzer to deliver real-time concentration and particle size analysis of oil, water, sand, and gas. It enables operators to test multiple points with one analyzer, verify results in the lab, and continuously measure particles from 0.7 to 20,000 microns at 30 frames per second. Designed to sample from the process stream without product loss, it provides accurate PPM/PPB and size distribution for refining and drilling optimization.

Min Fluid Velocity: 3 ft/s (If lower consult factory)

Max Fluid Velocity: 15 ft/s

MORE INFO
FUEL / LUBE OIL PARTICLE & WATER ANALYZER

Particles in lubricating and hydraulic oils are detrimental as they increase wear, clog filters, and accelerate oil degradation. Particle analysis assesses the capability of an online filtration system to clean the oil, and determines if off-line re-circulation filtration is required to clean the fluid, or whether a complete fluid change out is necessary. A high level of wear particles within the fluid is indicative of an impending component failure. Predictive maintenance by periodic lubrication oil analysis can be used to predict and prevent such failures.

MORE INFO
QUICKSAFE PIG LAUNCH

Features:

• Conforms to ASME Section B 31.1, B31.3 and PED
• Pressure ratings from full vacuum to 10,000 psi, 300F
• No bolting or Torqueing
• Zero Leak Closure
• Dual Seal
• Welded, ANSI or DIN mounting
• Duplex Stainless, Super Duplex, and various Alloys
• Sizes 1” – 20” available
• Optional NACE and corrosion liners

MORE INFO
OIL IN WATER – SKID MOUNTED INFLOW

The CANTY Inflow™ with CantyVision™ Software provides real-time, vision-based measurement of oil in water, accurately distinguishing oil, solids, and gas for reliable data. Unlike fluorescence monitors, it enables visual verification, droplet size analysis, and calibration to existing lab methods, helping optimize separator performance and chemical treatment. In-line monitoring and optional video recording ensure continuous analysis without missed production samples.

MORE INFO
OIL IN WATER & TSS

CANTY’s range of INFLOW™ analyzers combine the latest Gigabit Ethernet camera and microscopic optics technology, with our trademark fused glass, LED lighting systems, and CANTYVISION Intelligent Analysis™ software, to provide real time analysis (concentration & size) of Oil and Total Suspended Solids in Water.

Oil & TSS in Water Overview

MORE INFO
API SEPARATOR CONTROL

API separators are critical devices for water treatment in industries such as oil refineries and petrochemical plants. These separators remove oil and suspended solids from the water stream before it is further processed downstream. Separator outlets for solids, water and oil, as well as the baffle where oil flows above, require monitoring to ensure sufficient separation is occurring. CANTY’s field‑deployable systems provide real‑time monitoring of the various separator points and visual verification for operators, eliminating the need to enter the field.

MORE INFO
CH 10.10 Water & Solids in Oil

API 10.10 focuses on the on-line measurement of water content in petroleum and petroleum products. These include but are not limited to jet fuel, NGL, diesel, gasoline, and kerosene. This is a key measurement in custody transfer as it allows for quantification of the quality of the product being transferred, leading to any financial outcome of these transactions. The Canty Inflow™ provides three important functions to help you meet these industry standards.

MORE INFO
FREE WATER & TSS IN LNG

CANTY manufactures analyzers designed for the inline measurement of the concentrations and particle size and shape distributions of water and total suspended solids (tss) in LNG lines. Changes to temperature and pressure result in changes to the amount of water that can dissolve in this fluid. As such, making the measurement reliably and inline is critical to ensuring that free water does not damage equipment in your process. Other technologies require samples to be brought to a lab, can be influenced by different kinds of contaminants, and don’t reflect the same information that they would otherwise measure under the actual process conditions.

MORE INFO
POPCORN POLYMER

CANTY manufactures analyzers designed for the automated early detection of the formation of popcorn polymer. This includes measurements of the size and concentration of the polymer material as it first begins forming.

MORE INFO
